Imperial® IR-G48T-E Electric Pro Series Range - 48" Wide Griddle Range Over (2) Space Saver Ovens - 240V, 1PH
Model #: IR-G48T-E
Imperial®’s 48" Wide Electric Griddle Range delivers superb performance and reliability for busy commercial kitchens. The heavy-duty griddle features a ½” thick polished steel plate and full 21” (533) plate depth for more cooking surface. 3 KW serpen
View More
Starting Price:
$19,233.00
Start to Finish Support
Through our network of product experts, we offer a comprehensive solution that covers every stage of your equipment purchase.
- White-glove delivery, liftgate and equipment set in place
- Installation and start-up
- Equipment training and chef-led consultations
- Design services
- Confidence you are buying the right equipment for your operation
- Credibility in manufacturer-led purchasing
Note: Features and options may change based on your menu and operational needs. Submitting a request for a quote is the best way to consult with one of our product experts on the right product configuration.
Certifications:
Electrical Connection Hard Wired
This unit must be field wired per local code by a certified professional.
Warranty
1 Year Parts and Labor
Pro Install Required
This item requires professional installation.
Product Details
Imperial®’s 48" Wide Electric Griddle Range delivers superb performance and reliability for busy commercial kitchens. The heavy-duty griddle features a ½” thick polished steel plate and full 21” (533) plate depth for more cooking surface. 3 KW serpentine elements are located under the entire griddle plate and thermostat maintains selected temperature during peak hours. Includes a 4” (102) wide grease trough and removable grease can for easy cleaning. Each space saver oven features a high-performance 5.3 KW elements for even heating throughout the oven interior. It also includes a heavy duty thermostat with temperature range from 150°F to 500°F (65°C to 260°C) and the unique baffle above the element distributes heat flow for more even cooking temperatures. The oven interior measures 20”w x 26” d x 14” h (508 x 660 x 356) and is porcelainized, providing better browning and easier cleaning. The chrome oven rack accommodates standard sheet pans from front-to-back. The 6" heavy-duty legs include adjustable feet for leveling on uneven floors.
- Thick highly polished 3/4" (19 mm) steel plate with thermostat controls.
- 21" (533 mm) plate depth.
- Even heating elements across the griddle section provide consistent temperature across the plate.
- 4" (102 mm) wide grease trough and removable grease can for easy cleaning.
- Large griddle grease can is removable for easy cleaning.
- Porcelainized sides, rear, deck and door lining.
- Stamped inner door liner provides extra strength while optimizing heat retention.
- One chrome oven rack is included.
- Thick highly polished 3/4" (19 mm) steel plate with thermostat controls.
- 21" (533 mm) plate depth.
- Even heating elements across the griddle section provide consistent temperature across the plate.
- 4" (102 mm) wide grease trough and removable grease can for easy cleaning.
- Large griddle grease can is removable for easy cleaning.
- Porcelainized sides, rear, deck and door lining.
- Stamped inner door liner provides extra strength while optimizing heat retention.
- One chrome oven rack is included.
SKU (identifier) IR-G48T-E_240V_1PH
Construction Materials Stainless Steel
Cooking Area Plate Depth 21 in
Cooking Area Plate Width 48 in
Cooking Plate Finish Material Type Polished Steel
Oven Temperature Maximum 550 °F
Plate Thickness 0.5 in
Dedicated Circuit Required Yes
Electrical Hertz (frequency) 60 Hertz
Electrical Kilowatts 22.6 kW
Electrical Phase 1PH
Electrical Connection (Plug) Type Field Wired Per Local Code
Electrical Remarks See spec sheet for specific amp rates per oven.
Electrical Total Wattage 22600 W
Electrical Volts 240V
Primary Energy Type Electric
Product Clearance Required: Back 8 in
Product Clearance Required: Front 26 in
Product Clearance Required: Left Side 6 in
Product Clearance Required: Right Side 6 in
Product Clearance Required: Top 20 in
Product Depth 30.5 in
Product Height 36 in
Product Weight 811 lb
Product Width 48 in
WARNING
California Proposition 65
WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.p65warnings.ca.gov.
RESIDENTIAL USERS
RESIDENTIAL OR NON-COMMERCIAL INSTALLATION DISCLAIMER: The vendor assumes no liability for parts or labor coverage, component failure, including property damage, bodily injury, or death resulting from installation in a non-commercial or residential application. In addition, the warranty service provider network will only service equipment in a commercial location. The warranty will be voided if installed in non-commercial or residential locations.
